JP 10M3 Medical Oxygen Cylinder with CGA-540

Oxygen gas Cylinder Supplier

IS09809-1 10M3 JP medical oxygen gas cylinders are specialized high-pressure vessels designed for the storage and transportation of medical-grade oxygen.
These cylinders are supplied by reputable manufacturers and are suitable for use in various regions, including Peru, Ecuador, Bolivia, and other parts of South America.
The cylinders come in various sizes, including 40L, 47L, 50L, and 68L, offering flexibility to meet different medical oxygen supply needs.
They are constructed using seamless technology, ensuring high-pressure performance and reliability.

10M3 Medical Oxygen Cylinder

Oxygen tanks for residential, medical, commercial, and aviation use.
DSW Medical Oxygen Cylinder use first-class processing equipment and advanced processes to produce high-pressure steel seamless gas cylinders of various specifications, including 5-liter, 10-liter, 15-liter, 40-liter, and 50-liter gas cylinders.
In addition to the commonly used oxygen tanks, we can produce argon, nitrogen, neon, air, carbon monoxide, carbon dioxide and other cylinders.
They are used for medical and industrial purposes, such as steel mining, mountaineering, and diving.
Some common uses of industrial oxygen include Welding, cutting, flame cleaning, and metal manufacturing, such as steel production.

Feature

Working Pressure:150bar/200bar; Testing pressure: 250bar
Filling Medium: Air, Oxygen, Argon, Hydrogen, Helium, Nitrogen, Carbon dioxide
Equipped with various specifications of caps or valves(BS341, DIN477and CGA standard)
Manufacturing material: 37Mn/34CrMo4

Medical Oxygen cylinder sizes and capacities

10M3 Medical Oxygen Cylinder

CGA 540 Cylinder:
The CGA 540 valve is used for compressed oxygen (O2) cylinders. It is designed to handle high-pressure oxygen and includes safety features such as a pressure relief device to prevent overpressurization.

10M3 Medical Oxygen Cylinder

10M3 Medical Oxygen tanks

10M3 Medical Oxygen Cylinder

Oxygen TANKS

10M3 gas Cylinders For South America Market.

IS09809-1 10M3 JP medical Oxygen gas Cylinder With CGA540 Valve

Oxygen TANK

Medical Oxygen Cylinder sizes available in 47L, 150 Bar;10L, 150 Bar;16 Cylinder Pallets,Other Sizes and Pressures on Asking

Additional information

Condition:

New

Brand Name:

JP brand

Machinery Test Report:

Provided

Warranty of core components:

Not Available

Dimension(L*W*H):

229*1485mm

Weight:

56kg

Inner Material:

34CrMo4

Design Pressure(MPa):

30Mpa

Design Standard:

ISO9809-1:2010

Warranty:

3 months

Key Selling Points:

High Productivity

After Warranty Servi

Online support

Showroom Location:

None

Working Pressure:

200bar

Outside Diameter:

229mm

Place of Origin:

Zhejiang, China

Video outgoing-inspection:

Provided

Marketing Type:

Pressure vessel

Capacity:

10M3

Volume (m³):

0.057M3

Outer Material:

34CrMo4

Max Working Pressure(MPa):

20 MPa

Working Temperature(℃):

-20 – 60 ℃

After-sales Service Provided:

Video technical support

Applicable Industries:

Hotels, Manufacturing Plant, Restaurant, Home Use, Food Shop,

Local Service Location:

None

Water Capacity:

50L oxygen Cylinder

Test Pressure:

300bar Oxygen Gas Cylinder
